Heyco® Braided Sleeving

  • Part Numbers and Specifications
  • Features
BUNDLE RANGE PART NO. DESCRIPTION PART DIMENSIONS
Minimum
Diameter
Maximum
Diameter
Black FR
Black
Nominal
Diameter
Quantity
Per Spool
in. mm. in. mm. in. mm. ft. mtrs.
.09 2,3 .25 6,4 8980 8983 BS 125 .13 3,2 1000 305
.13 3,2 .44 11,1 8985 8988 BS 250 .25 6,4
.25 6,4 .75 19,1 8990 8993 BS 500 .50 12,7 500 152
.50 12,7 1.25 31,8 8995 8998 BS 750 .75 19,1 250 76
.75 19,1 1.75 44,5 9000 9003 BS 1250 1.25 31,8
1.25 31,8 2.75 69,9 9005 9008 BS 1750 1.75 44,5 200 61
1.50 38,1 3.50 88,9 9010 9013 BS 2.0 2.00 50,8

Standard color black.
FR sleeving flammability rating - UL VW-1.

  • Braided sleeve slips on quickly and is self-fitting over irregular shapes and contours. No wire pulling compounds are required due to its low surface friction. Slight tensioning after application makes for an even tighter fit.
  • Expandable up to three times its own diameter, the open-weave construction can fit many applications, simplifying inventory. The open-weave allows for easy inspection of sleeved components and easy break out of individual cables.
  • Full cable flexibility is maintained in any direction, even at low temperatures. Wires encased in Heyco Braided Sleeving can flex and bend as readily as if they had no protective oversleeving. Bundles can be flexed repeatedly without damage.
  • Tough, cut-resistant sleeving is designed for protecting wire bundles and harnesses, hoses, tubing, and cable assemblies from mechanical damage and environmental hazards.
  • Preferred cutting method: hot knife.

QuickSpecs

Materials   Polyester Monofilament Yarns or Flame Retardant Polyester Yarn
Certifications ru Recognized under the Component Program of Underwriters' Laboratories File E173954
Monofilament Diameter   .010"
Temperature Range   -103°F (-75°C) to 257°F (125°C)
