| MOUNTING HOLE DIAMETER* |
PART NO. | DESCRIPTION | PART DIMENSIONS | ||||
|---|---|---|---|---|---|---|---|
| Matte | A Head Diameter |
B Overall Height |
|||||
| in. | mm. | in. | mm. | in. | mm. | ||
Multiple Locking Steps for Panel Thickness up to .125" (3,2 mm) |
|||||||
| .375 | 9,5 | 1303D | DWP 375 | .47 | 11,9 | .41 | 10,3 |
| .760 | 19,3 | 1309D | DWP 750 | .92 | 23,4 | ||
| 1.000 | 25,4 | 1312D | DWP 1000 | 1.13 | 28,6 | .45 | 11,5 |
| 2.000 | 50,8 | 1319D | DWP 2000 | 2.16 | 54,8 | ||
*Consult Heyco for other mounting hole diameters.
| Material | Polycarbonate |
|---|---|
| Flammability Rating | 94V-2 |
| Temperature Range | -40°F (-40°C) to 239°F (115°C) |
