| PART SPECIFICATIONS | PART NO. and DESCRIPTION | PART DIMENSIONS | STYLE | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nytye Max. Tensile Strength | Nytye Max. Bundle Diameter | NYTYE Black | Description | PUSH RIVET Black | A Length | B Width | Assembled Panel Thickness | Mounting Hole Dia. | |||||||||
| Lbs. | N | in. | mm. | in. | mm. | in. | mm. | in. | mm. | in. | mm. | in. | mm. | ||||
Nytye Fixed Rivet |
|||||||||||||||||
| 88 | 392 | 1.69 | 43,0 | 13430B* | NTPR-88-067-256 | N/A | 6.65 | 169,0 | .35 | 9,0 | .04 | 1,0 | .08 | 2,0 | .256 | 6,5 | 1 |
Nytye Push Rivet |
|||||||||||||||||
| 88 | 392 | 1.69 | 43,0 | 13431B** | NTPR-88-067-161 | 9058 | 6.65 | 169,0 | .35 | 9,0 | .03 | 0,8 | .07 | 1,8 | .161 | 4,1 | 2 |
| 9060 | .07 | 1,8 | .11 | 2,8 | |||||||||||||
| 9062 | .11 | 2,8 | .15 | 3,8 | |||||||||||||
| 9064 | .15 | 3,8 | .19 | 4,8 | |||||||||||||
| 9066 | .19 | 4,8 | .23 | 5,8 | |||||||||||||
| 9068 | .23 | 5,8 | .27 | 6,8 | |||||||||||||
| 9318 | .29 | 7,3 | .35 | 8,8 | |||||||||||||
| 13432B** | NTPR-88-067-201 | 9072 | .03 | 0,8 | .07 | 1,8 | .201 | 5,1 | |||||||||
| 9074 | .07 | 1,8 | .11 | 2,8 | |||||||||||||
| 9076 | .11 | 2,8 | .15 | 3,8 | |||||||||||||
| 9078 | .15 | 3,8 | .19 | 4,8 | |||||||||||||
| 9080 | .19 | 4,8 | .23 | 5,8 | |||||||||||||
| 9082 | .23 | 5,8 | .27 | 6,8 | |||||||||||||
| Material | UL 94 V-2 PA 66 |
|---|---|
| Temperature Range | 32°F (0°C) to 185°F (85°C) |
